UV Curing Oven (HT-UV1)

Features

• 1. Mold-opened rail design: Molded track structure with stainless-steel chain conveyor and protective chain guides to extend track service life
• 2. Parameterized conveyor speed: Transport speed can be set on the touchscreen.
• 3. Digital intelligent energy adjustment: The lamp power percentage can be set.system enters energy-saving mode automatically when no board is detected or during standby
• 4. Patented furnace air-circulation system: Special exhaust design with front, rear, side, and bottom air extraction for controlled and stable chamber temperature to ensure the stable performance.
• 5. Patented lamp-box design: Four-channel airflow structure reduces product surface temperature, increases UV reflection efficiency, minimizes light loss, and protects operators; lamp modules can be replaced within 10 minutes.
• 6. Open-frame design: Acrylic front door structure offers excellent accessibility for operation, maintenance, and removing dropped boards
• 7. Dual-layer UV-blocking viewing window: One heat-insulation layer and one UV light-shielding layer allow real-time and safe monitoring; window can be closed when not in use
• 8. Adjustable lamp height: Manual adjustment range 0–100 mm
• 9. Inlet/outlet exhaust: Removes ozone and curing odors generated during the UV process
• 10. High compatibility: Supports PCB with component heights up to ±100 mm (100 mm above or below)
